QHY 6060 BSI Class 2 Cooled Scientific CMOS Camera

Brand: QHY

SKU : QH-QHY6060-BSI-2

- Read
Add to Wishlist

Request stock alerts and we'll let you know when the item is back in stock

Got questions? Click for live chat

  • Big format scientific CMOS camera with 37.7 Megapixel, 61mm square (89mm diagonal)
  • Has both a back-illuminated version and a front-illuminated version
  • Has a 2-stage TEC cooler and it is air-cooling / water cooling compatible
  • QHYCCD can offer a special customized design of the full vacuum version. Please contact QHYCCD if you need this version.

Product Details

  • QHY6060 is a big format scientific CMOS camera with 37.7 Megapixel, 61mm square (89mm diagonal) Gpixel Gsense6060 sensor, 10um pixel size, 14bit ADC, 6K*6K resolution. It has both a back-illuminated version and a front-illuminated version. The FSI version has 72% peak QE and the BSI version has 95% peak QE

    QHY6060 has a 2-stage TEC cooler and it is air-cooling / water cooling compatible. QHY6060 has USB3.0 high-speed interface.

    The BSI QHY6060 also has a soft X-ray response. In order to use it in a full vacuum environment. The camera needs to be put into a vacuum environment. QHYCCD can offer a special customized design of the full vacuum version. Please contact QHYCCD if you need this version.

    Mechanical Dimensions



    Curves


  • specifications

    ADC14 bit
    CooledCooled
    Cooling Below Ambient47C
    Dynamic Range13.9 Stops
    Full Well70ke
    Mega Pixels37.6 MP
    MPMore than 20 MP
    Peak QE95%
    Pixel Array6134 x 6134
    Pixel Size10 microns
    PS10 Microns or Larger
    Read Noise4.7e
    Sensor Diagonal86.7mm
    Sensor TypeCMOS
    SensorGPixel GSENSE6060 BSI
    Weight1.2 lb
  • included items

    • QHY 6060 BSI Class 2 Cooled Scientific CMOS Camera
