ZWO 2-Inch Filter Drawer - M42 Thread

Brand: ZWO

SKU : ZWO-FD-M42-II

- Read
Add to Wishlist

Request stock alerts and we'll let you know when the item is back in stock

Got questions? Click for live chat

  • All old versions of the ZWO F-HLDRs are NOT compatible with this new filter drawer

The ZWO 2-inch Filter Drawer has an M42 thread with 21 mm ring design.

  • Side A: M42 * 0.75" male thread (camera side).
  • Drawer: M48 * 0.75" female thread (filter).
  • Side B: M48 * 0.75" female thread (telescope side).
  • Magnets installed to hold the drawer securely.
  • M48-M42 Adapter

Product Details

  • ZWO 2-inch Filter Drawer (M42 Thread) with 21 mm ring design includes:

    • Side A: M42 * 0.75" male thread (camera side).
    • Drawer: M48 * 0.75" female thread (filter).
    • Side B: M48 * 0.75" female thread (telescope side).
    • Click on the Gallery thumbnail to view mechanical drawing.

    ZWO Filter Drawer - M42 Thread-wide

    There are double strong magnets to create a stronger adsorption hold, easier installation, and easier drawer removal.

  • specifications

    Back Focus21 mm
    Camera/Eyepiece Side ConnectionMale M42x0.75
    Filter ConnectionFemale M48x0.75
    Scope Side ConnectionFemale M48x0.75
  • included items

    • ZWO 2-Inch Filter Drawer - M42 Thread
