SBIG Aluma 694 Camera Pro Package with WiFi/USB Interface

Brand: SBIG


- Read
Looking for a SBIG Aluma 694 Camera Pro Package with WiFi/USB Interface? Shop this product at Agena Astro by clicking the SHOP NOW button!
Add to Wishlist

Request stock alerts and we'll let you know when the item is back in stock

Got questions? Click for live chat

  • Excellent performance research grade CCD Camera
  • Sensor: Sony ICX-694ALG
  • Type: Interline Transfer- Research Grade
  • Pixel Array: 2750 x 2200
  • Pixel Size: 4.54 Microns
  • Sensor Diagonal: 14.6 mm x 12.8 mm
  • Wi-Fi functional

Product Details

  • SBIG Aluma 694 Pro Package also includes:

    • 8-Position Self Guiding Filter Wheel
    • 36mm LRGB Filter Set
    • 36mm Narrowband 3-Filter Set

    The Aluma 694 is a high sensitivity research-grade Interline CCD camera using the popular Sony ICX-694ALG imaging sensor for high-quality results. It can boast several features that are unique among research-grade CCD cameras; it includes two-stage cooling, USB 2.0 and WiFi 802.11 b/g/n interfaces, ultra-reliable even-illumination shutter, and fast low-noise readout. The Aluma 694 can be operated remotely through Wi-Fi using a tablet, smartphone, or any kind of personal computer. It is compatible with Windows, Mac, and Linux operating systems.

    The mechanical shutter in use with the Aluma 694 has a minimum exposure time of 0.001 seconds, and a staggering maximum exposure time of 49 days, meaning that in most practical sessions it can go for as long as you would ever feasibly need. The inbuilt cooling system is a powerful TE system using two-stage cooling in the form of a pair of variable speed fans and a high-efficiency heat sink. The maximum cooling delta of this temperature control system is -50 Celsius below the surrounding temperature.

  • specifications

    ADC16 bit
    Color or MonoMonochrome
    Delta T50C
    Dynamic Range12.5 Stops
    Full Well25ke
    Mega Pixels6.1 mp
    Peak QE75%
    Pixel Array2750 x 2200
    Pixel Size4.54 microns
    Read Noise4.5e
    Sensor Diagonal16mm
    Sensor TypeCCD
    SensorSony ICX 694
    Weight2.2 lbs
  • included items

    • Aluma 694 Camera
    • Maxim AL Software
    • iOS / Android software coming soon (via app store)
    • Deluxe carrying case
    • Universal power supply (110V / 220V, 50-60 Hz)
    • 2" Nosepiece adapter
    • USB flash drive containing software, drivers, and documentation
    • 15 foot (4.5 m) USB cable
    • Tracking interface cable
    • SBIG Aluma 8-Position Self-Guiding Filter Wheel
    • 36mm LRGB Filter Set
    • 36mm Narrowband 3-Filter Set
