QHY 5III678 Color Planetary Camera & Guider

Brand: QHY

SKU : QH-QHY5III678C

- Read
Looking for a QHY 5III678 Color Planetary Camera & Guider? Shop this product at Agena Astro by clicking the SHOP NOW button!
SHOP NOW
Add to Wishlist

52D158B8-B55E-4DF3-8064-D4A13DFFDDC4 Request stock alerts and we'll let you know when the item is back in stock

Got questions? Click for live chat

  • Larger 512MB DDR3 image buffer
  • Improved front end design
  • CS and C-mount lens compatibility
  • USB 3.2 Type C interface
  • Universal ST-4 guiding port
  • Status indicator LED
  • 1.25" body size for maximum compatibility

Product Details

  • The QHY5III678C is the latest addition to the new Version 2 line of QHY5III Series planetary cameras and guiders. The QHY5III678C may be considered an enhanced version of its predecessor, the QHY5III178C. Like the IMX178, Sony’s new IMX678 is a back-illuminated 1/1.8-inch format sensor. However, the IMX678 has higher resolution and higher QE plus enhanced NIR sensitivity. In addition, the QHY5III678C cameras are built on the new v.2 platform with improved features.

    Extended Near Infrared Sensitivity

    In this latest generation of sensors, the photodiode portion of the IMX678’s pixel well is physically deeper than in previous sensors, allowing photons of longer wavelengths to penetrate deeper into the substrate. This dramatically increases the sensor’s sensitivity to red and near-infrared (NIR) light. The sensor displays almost equal peak sensitivity to NIR light as it does to light in the visible spectrum.

    New QHY5III v.2 Models

    As the third model in the latest generation of planetary cameras and guiders, the QHY5III678M includes all of the improvements and upgrades found in this latest series of cameras, including:

    • Larger 512MB DDR3 image buffer
    • Improved front end design
    • CS and C-mount lens compatibility
    • USB 3.2 Type C interface
    • Universal ST-4 guiding port
    • Status indicator LED
    • 1.25" body size for maximum compatibility
  • specifications

    ADC12 bit
    Back Focus8mm
    Built in Image Buffer512MB DDR3 Memory
    Camera Connection1.25" Nosepiece
    Color or MonoColor
    Computer InterfaceUSB3.2 Gen1 Type C
    Guide PortUniversal ST 4 compatible
    Max Frame Rate41fps
    Mega Pixels8.4 MP
    Pixel Array3856 x 2180
    Pixel Size2 microns
    Read Noise3.3e
    Sensor TypeCMOS
    SensorSony IMX678 BSI
    Shutter TypeElectronic Rolling Shutter
    Solar Scope TypePlanetary
    Weight0.198 lb
  • included items

    • QHY 5III678 Color Planetary Camera & Guider
