Astronomik OIII 12nm CCD Filter - 50mm Square Unmounted

ITEM #
AK-OIIICCD-50SQ
  • Sale
  • Regular price $329.95
  • Astronomik OIII 12nm CCD Filter - 50mm Square Unmounted

    • Sale
    • Regular price $329.95
    • ITEM #
      AK-OIIICCD-50SQ


    0

    Features

    Astronomik OIII 12nm CCD Filter - 50mm Square Unmounted

    Astronomik OIII 12nm CCD Filter - 50mm Square Unmounted

    The Astronomik OIII CCD filter is a narrow band emission-line-filter for CCD photography. The filter lets the light of double ionized Oxygen of emission nebulae pass and blocks nearly the whole remainder of the spectrum where the CCD is sensitive.

    The full width at half maximum (FWHM) of 12 nm is optimal suitable for common CCD cameras and allows the use of very fast optics The optimal aperture ratio for the use of the filter is 1:3 to 1:15 with apertures of more than 6" (150mm). It should be noted that the filter has a transmission of up to 99%, which cannot be attained by stacking more narrow-band filters. A further note, which led to selecting the half width (FWHM), is the dark current of common CCD imagers. Exposures with a CCD cooled to -15???C are limited by the dark current of the CCD, even in large cities with a bright background. Another advantage of the 12 nm filter is the better availability of guiding stars for cameras with a built-in-autoguider (SBIG). If you use a very strong filter like our H-alpha 6nm filter you often wonƒ???????????t find a usable guidestar.

    Together with our other three Astronomik emission-line filters you can do great color images even from very light polluted places!

    The Astronomik OIII CCD increases the contrast between objects, in this case between the OIII emission line and the skyglow background. Our Astronomik OIII CCD completely suppresses the emission lines of artificial lighting (mercury (Hg) and sodium (Na)) and skyglow. Transmission losses and chromatic distortions, which arise with other filters, only occur with Astronomik filters when extremely bright aperture ratios of 1:2 and more come into play. The filter has a built-in IR-blocker up to 1150nm. You donƒ???????????t need an additional IR-blocker with this filter.

    When using the Astronomik OIII CCD filter together with the H-alpha, OIII CCD and the SII CCD filters you can obtain three-color images of emission line objects (gas nebulae) from locations with very strong light pollution. To do so, you would take an image in three different wavelengths, select each one as a color-channel in Photoshop and paste them together as one single color image.

    If you plan to create color images from emission line data, our CLS CCD filter is a great choice for the Luminance channel The OIII CCD is also great for visual observation. If you plan to get filters for visual observation and for astrophotography get the CCD filter: You may use this filter visual as well as in front of you camera. The built-in IR-blocker doesnƒ???????????t disturb visual observation but you need an additional IR-blocker if you want to use the visual filter with your camera.

    Astronomik OIII 12nm CCD Filter - 50mm Square Unmounted Features.

    • 95% transmission at 496nm (OIII)
    • 95% transmission at 501nm (OIII)
    • Full width at half maximum 12nm
    • Transmission from 494nm to 506nm
    • Parfocal with other Astronomik filters
    • Glass thickness: 1mm
    • Completely resistant against high humidity, scratches and aging effects
    • Diffraction limited, the filter will not reduce the optical performance of your telescope!
    • Astronomik filters are delivered in a high-quality, long lasting, filter box
    Astronomik Product Number: OIIICCD-50SQ

    Additional Information

    Filter TypeOIII
    Free ShippingYes
    ManufacturerAstronomik
    ShapeSquare
    Size50mm
    Warranty10 Year Warranty
