Orion Atlas II EQ-G Equatorial GoTo Mount and Tripod

SKU : OR-08269

- Read
  • Call for Availability

  • Extended Backorder

Add to Wishlist

52D158B8-B55E-4DF3-8064-D4A13DFFDDC4 Request stock alerts and we'll let you know when the item is back in stock

Got questions? Click for live chat

  • Load capacity of 44-pounds
  • Dual stepper motors
  • Dual width saddle
  • New features on the drive panel
  • Built-in illuminated polar scope
  • SynScan hand controller
  • Heavy-duty tripod and two Counterweights



Product Details

  • The Orion Atlas II EQ-G Equatorial GoTo Mount and Tripod improves upon the venerable Atlas EQ-G by incorporating more than a dozen enhanced features and specifications.

    Now with a load capacity of 44-pounds it is perfect for rock-solid support of your optical tubes and imaging trains used by serious astroimagers. At nearly 40-pounds, the equatorial head now sports a large handle to make lifting it onto and off of the tripod much easier.

    The Atlas II uses dual stepper motors with belt drives for whisper-quiet slewing, reduced backlash, and improved guiding accuracy. The mount's latitude adjustment has been beefed-up with big bolts that work even with a full telescope load.

    Orion Atlas II EQ-G Equatorial GoTo Mount and Tripod-wide

    The dual width saddle is compatible with both D- and V-style mounting plates.

    New features of the drive panel include a USB port for controlling the mount via computer using optional 3rd party software. A SNAP port has been added to allow DSLR camera shutter control with the SynScan controller for astrophotography. The 12V power cable now threads onto the jack for a more secure connection.

    The Atlas II's built-in illuminated polar scope works in both Northern and Southern hemispheres and features a graduated clock-face reticle for more accurate polar alignment.

    The SynScan hand controller contains a 42,9000-object database and a array of practical features and functions. There is a Tour mode that takes you to the best object each night, permanent periodic error correction (PPEC), pointing accuracy enhancement (PAE), DSLR camera control, slewing limits, parking, ASCOM compatibility, and a USB port for updating firmware.

    The heavy-duty tripod is equipped with 2-inch extendable stainless steel legs and a spreader/ accessory tray.

    Counterweights: Included with this mount and tripod set-up are two 11.5-pound counterweights.



    Manufacturer's Note: The Atlas II EQ-G requires a power supply (sold separately) with an output Voltage of 11 to 16V and an output Current of 4 Amps.

    -

  • specifications

    ComputerizedComputerized
    Counterweight11.5 lb/ Includes 2
    Database429000 Objects
    Drive TypeBelt
    Head DesignEquatorial
    Instrument Capacity44 lb
    Motor DriveDual Stepper Motors
    Mount Head Weight40lb
    PECYes
    PortsSNAP
    PortsUSB
    Telescope ConnectionDual Vixen & Losmandy
    Total Weight40 lb
  • included items

    • Load capacity of 44-pounds
    • Dual stepper motors
    • Dual width saddle
    • New features on the drive panel
    • Built-in illuminated polar scope
    • SynScan hand controller
    • Heavy-duty tripod and two Counterweights
