• The ZWO ASI120MM-S Super Speed Camera is a perfect choice for lunar and planetary imaging! It features a CMOS sensor, sensitive enough to capture bright deep-sky objects. An ideal choice for the serious beginner or intermediate astrophotographer.

  The ZWO ASI120MM-S Specs at a Glance



  Experience the ZWO ASI120MM-S Monochrome Camera

  Accelerated Performance

  Switch from planetary to deep space imaging without having to weigh down your set up. The ZWO ASI120MM produces frames with 254 per second with reduced resolution or 60 frames per second at full resolution.Download your images at lightning speed with the USB 3.0 connection.

  Optimum Design

  Encamped in a vibrant, metallic red aluminum housing andwith both a USB and ST4 autoguider port, the ZWO ASI120MM-S is convenient and versatile. Easily attach a wide variety of camera mounts and tripods with its one-fourth-inch-20 threadin the center bottom of the camera or any of its four M4 threads along the outside edge.

  Prioritized Mechanics

  • Built on a one-third inch CMOS AR0130S monochrome sensor. Spectacular details are revealed in high-resolution black and white. Pair with a filter wheel to capture each color or narrowband and stack images as you choose.
  • The pixel array of 1280 x 960 and a pixel size of 3.75-micron square make this camera capable of capturing moderately wide fields when used with the included 150-degree wide-angle lens adapter.
  • Peak QE is 75% with absolutely no fixed pattern noise. Protecting the sensor is an IR-cut window.

   OPT Product Number: ZWO-ASI120MM-S



• specifications

  ADC	12 bit
  Back Focus	12.5 mm
  Camera Connection	Female M42x0.75
  Color or Mono	Monochrome
  Cooled	Uncooled
  Dynamic Range	11.6 Stops
  Free Shipping	Yes
  Full Rez Frame Rate	60fps
  Full Well	20ke
  Max Frame Rate	254fps
  Mega Pixels	1.2 mp
  Peak QE	78%
  Pixel Array	1280 x 960
  Pixel Size	3.75 microns
  Read Noise	6.6e
  Sensor Diagonal	6 mm
  Sensor Type	CMOS
  Sensor	On Semi AR0130CS
  Weight	0.2 lbs

• included items

  • ZWO ASI120MM-S Monochrome 1.2 Mega Pixel Astronomy Camera.
  • 150-degree Lens Adapter for use as an all-sky camera.
  • M42 to 1.25-inch nosepiece.
  • 1.25-inch IR-cut window.
  • 2 m long USB cable.
  • 2 m long ST4 guider cable.
  • Driver and Extra Software CD.
